Part Number	Title	Category	Application	Pattern	Polarization	F Low (MHz)	F High (MHz)	Gain (dB)	TID (krad)
PW0404-100	PW0404-100: UHF Linearly Polarized Antenna	Space Antennas	TT&C	Omni	Linear	395	405	0.5
PW0404-300	PW0404-300: UHF Linearly Polarized Test Hat	Space Antenna Test Hats	TT&C		Linear	395	405
PW1115-002	PW1115-002: Active GNSS L1/E1/L2/L5/E5 Antenna	Space Antennas	GNSS/GPS	Omni	RHCP	1164	1591	18.5	3000
PW1115-302	PW1115-302: GNSS L1/E1/L2/L5/E5 Test Hat	Space Antenna Test Hats	GNSS/GPS		RHCP	1164	1591
PW1515-001	PW1515-001: Active GPS L1 Antenna	Space Antennas	GNSS/GPS	Omni	RHCP	1563.42	1587.42	20	250
PW1515-004	PW1515-004: Active GNSS L1/E1 Antenna	Space Antennas	GNSS/GPS	Omni	RHCP	1559	1591	20	3000
PW1515-301	PW1515-301: GPS L1 Test Hat	Space Antenna Test Hats	GNSS/GPS		RHCP	1563.42	1587.42
PW1515-304	PW1515-304: GNSS L1/E1 Test Hat	Space Antenna Test Hats	GNSS/GPS		RHCP	1559	1591
PW1516-100	PW1516-100: L-Band RHCP Wideband Omni Antenna	Space Antennas	Data	Omni	RHCP	1513	1675	5
PW1516-300	PW1516-300: L-Band RHCP Wideband Omni Test Hat	Space Antenna Test Hats	Data		RHCP	1513	1675
PW2020-000	PW2020-000: Active S-Band RHCP RX Omni Antenna	Space Antennas	TT&C	Omni	RHCP	2025	2110	32.5	500
PW2020-110	PW2020-110: S-Band Dual-CP RX Omni Antenna	Space Antennas	TT&C	Omni	RHCP/LHCP	2025	2110	4.5
PW2020-310	PW2020-310: S-Band Dual-CP RX Omni Test Hat	Space Antenna Test Hats	TT&C		RHCP/LHCP	2025	2110
PW2022-101	PW2022-101: S-Band RHCP Wideband Omni Antenna	Space Antennas	TT&C	Omni	RHCP	2025	2290	5.5
PW2022-102	PW2022-102: S-Band RHCP Dual-Port (TX+RX) Omni Antenna	Space Antennas	TT&C	Omni	RHCP	2025	2290	4.5
PW2022-111	PW2022-111: S-Band Dual-CP Wideband Omni Antenna	Space Antennas	TT&C	Omni	RHCP/LHCP	2025	2290	5.5
PW2022-301	PW2022-301: S-Band RHCP Wideband Omni Test Hat	Space Antenna Test Hats	TT&C		RHCP	2025	2290
PW2022-302	PW2022-302: S-Band RHCP Dual-Port (TX+RX) Omni Test Hat	Space Antenna Test Hats	TT&C		RHCP	2025	2290
PW2022-311	PW2022-311: S-Band Dual-CP Wideband Omni Test Hat	Space Antenna Test Hats	TT&C		RHCP/LHCP	2025	2290
PW2222-101	PW2222-101: S-Band RHCP TX 2×2 Antenna	Space Antennas	TT&C	Directional	RHCP	2200	2290	11
PW2222-110	PW2222-110: S-Band Dual-CP TX Omni Antenna	Space Antennas	TT&C	Omni	RHCP/LHCP	2200	2290	4.5
PW2222-301	PW2222-301: S-Band RHCP TX 2×2 Test Hat	Space Antenna Test Hats	TT&C		RHCP	2200	2290
PW2222-310	PW2222-310: S-Band Dual-CP TX Omni Test Hat	Space Antenna Test Hats	TT&C		RHCP/LHCP	2200	2290
PW3017-100	PW3017-100: K-Ka-Band Dual-Port (RHCP+LHCP) Waveguide Probe Antenna	Horn Antennas	TT&C \| Data	Directional	RHCP/LHCP	17000	30000	8
PW3017-115	PW3017-115: K-Ka-Band Dual-Port (RHCP+LHCP) Horn Antenna, 15 dB	Horn Antennas	TT&C \| Data	Directional	RHCP/LHCP	17000	30000	15
PW3017-120	PW3017-120: K-Ka-Band Dual-Port (RHCP+LHCP) Horn Antenna, 20 dB	Horn Antennas	TT&C \| Data	Directional	RHCP/LHCP	17000	30000	20
PW4010-101	PW4010-101: Quad-Ridged Horn Antenna, 10 to 40 GHz	Horn Antennas	TT&C \| Data	Directional	Dual Linear	10000	40000	8
PW4018-100	PW4018-100: Dual-Ridged Horn Antenna, 18 to 40 GHz	Horn Antennas	TT&C \| Data	Directional	Linear	18000	40000	10
PW8282-101	PW8282-101: X-Band RHCP TX 2×2 Antenna	Space Antennas	TT&C	Directional	RHCP	8025	8400	10
PW8282-102	PW8282-102: X-Band RHCP TX 2×2 Antenna	Space Antennas	TT&C	Directional	RHCP	8025	8500	9
PW8282-103	PW8282-103: X-Band RHCP TX Switched-Beam Hemispherical Antenna Module	Space Antennas	TT&C	Directional (Switched Beam)	RHCP	8025	8500	9
PW8282-301	PW8282-301: X-Band RHCP TX 2×2 Test Hat	Space Antenna Test Hats	TT&C		RHCP	8025	8400
PW8282-302	PW8282-302: X-Band RHCP TX 2×2 Test Hat	Space Antenna Test Hats	TT&C		RHCP	8025	8500
